Application:
This submersible pump is used to transfer surplus rain water, emptying ponds and
pools, to convey the stream water or ditches water. It can be used also
in Industrial air-washer machines.
Technical characteristics
:
Pump
SP with delivery size of 1¼" , 2" and 3", narrow outlet delivery
and upgrade delivery has been designed for 220V and 380V with 10%
voltage network oscillation. The casing of main frame is made of
stainless steel in which the water circulates the casing sidewall and
cools the dynamo. The delivery is upgrade.
Parts:
All parts of pump and the impeller are made of a special alloyed
aluminum, the shaft and all screws of stainless steel which increase
greatly the resistance of SPICO Drainage Pumps against corrosion.
Paint:
After final manufacturing and testing of all parts made of
aluminum and before painting them, they are degreased in specific small
pools and then acid dipping to get high resistance against the salts
soluble in water.
Cable: Use of special cable of
EPDM
and CPE types to resist against salts
soluble in water, moisture and acid or alkaline water.
Mechanical
seal: Using anti-abrasive seals (Silicon Carbide) with high
quality to increase pump lifetime. To supply high quality and more
reliable pumps and to increase the mechanical seals lifetime, SPICO has
applied a special chamber full of oil between pump and electro motor
which are sealed by using two mechanical seals and two oil seals which
the oil can be controlled by an Allen screw no.8.
Porosity
impregnation: All casting parts have been alloyed by professional
experts to avoid any pores or minute leaks in them. However, SPICO
performs Porosity Impregnation process for main casting parts by using
special machines and resin. So the electro motor penetrability to water
reaches zero.
ID:
All SPICO products have a serial no., engraved on pump casing, which is
known as their identification no. This number specifies the production
file and the technical ID of each pump which are kept in Company filing
system.
Guarantee: All SPICO products, according to attached warranty
terms, are guaranteed for SIX MONTHS upon purchase date. Using high
protective systems for pumps are recommended.
