Asynchronous three phase motors 2 pole |
||||
|
|
||||
| Mec | KW | RPM | POLE | Description |
| 56 | 0.09 | 2830 | 2 | S 80.40 H45 |
| R 40.15 H45 AL1,5 8 | ||||
| 56 | 0.12 | 2720 | 2 | S 80.40 H55 |
| R 40.15 H55 AL1,5 8 | ||||
| 63 | 0.18 | 2820 | 2 | S 90.47 H50 |
| R 47.18 H50 AL1,5 6,8 | ||||
| 63 | 0.25 | 2860 | 2 | S 90.47 H65 |
| R 47.18 H65 AL1,5 6,8 | ||||
| 71 | 0.37 | 2880 | 2 | S 110.55 H50 |
| R 55.20 H50 AL1,5 7,6 | ||||
| 71 | 0.55 | 2890 | 2 | S 110.55 H65 |
| R 55.20 H65 AL1,5 7,6 | ||||
| 80 | 0.75 | 2800 | 2 | S 125.65 H60 |
| R 65.25 H60 AL1,5 7 | ||||
| 80 | 1.1 | 2840 | 2 | S 125.65 H80 |
| R 65.25 H80 AL1,5 7 | ||||
| 90 | 1.5 | 2800 | 2 | S 135.70 H75 |
| R 70.30 H75 AL1,5 11P | ||||
| 90 | 2.2 | 2860 | 2 | S 135.70 H100 |
| R 70.30 H100 AL1,5 11P | ||||
| 100 | 3 | 2860 | 2 | S 152.80 H90 |
| R 80.36 H90 Al1,5 10,5P | ||||
| 112 | 4 | 2920 | 2 | S 173.90 H110 |
| R 90.38 H110 AL1,5 12P | ||||
| 132 | 5.5 | 2870 | 2 | S 200.110 H90 |
| R 110.50 H90 AL 1,5 14 P | ||||
| 132 | 7.5 | 2920 | 2 | S 200.110 H120 |
| R 110.50 H120 AL 1,5 14 P | ||||
| Asynchronous three phase motors 4 pole | ||||
| Mec | KW | RPM | POLE | Description |
| 56 | 0.06 | 1380 | 4 | S 80.45 H45 |
| R 45.15 H45 AL1,5 8 | ||||
| 56 | 0.09 | 1380 | 4 | S 80.45 H55 |
| R 45.15 H55 AL1,5 8 | ||||
| 63 | 0.12 | 1390 | 4 | S 90.50 H45 |
| R 50.18 H45 AL1,5 7,5 | ||||
| 63 | 0.18 | 1400 | 4 | S 90.50 H60 |
| R 50.18 H60 AL1,5 7,5 | ||||
| 71 | 0.25 | 1400 | 4 | S 110.66 H50 |
| R 66.20 H50 AL1,5 8 | ||||
| 71 | 0.37 | 1400 | 4 | S 110.66 H65 |
| R 66.20 H65 AL1,5 8 | ||||
| 80 | 0.55 | 1410 | 4 | S 125.80 H60 |
| R 80.25 H60 AL1,5 10,5P | ||||
| 80 | 0.75 | 1420 | 4 | S 125.80 H80 |
| R 80.25 H80 AL1,5 10,5P | ||||
| 90 | 1.1 | 1400 | 4 | S 135.80 H75 |
| R 80.30 H75 AL1,5 10,5P | ||||
| 90 | 1.5 | 1400 | 4 | S 135.80 H100 |
| R 80.30 H100 AL1,5 10,5P | ||||
| 100 | 2.2 | 1430 | 4 | S 152.90 H90 |
| R 90.36 H90 AL1,5 12P | ||||
| 100 | 3 | 1440 | 4 | S 152.90 H120 |
| R 90.36 H120 AL1,5 12P | ||||
| 112 | 4 | 1430 | 4 | S 173.103 H140 |
| R 103.38 H140 AL1,5 11PA | ||||
| 132 | 5.5 | 1440 | 4 | S 200.125 H125 |
| R 125.50 H125 AL 1,5 14 P | ||||
| 132 | 7.5 | 1440 | 4 | S 200.125 H170 |
| R 125.50 H170 AL 1,5 14 P | ||||
 |
||||
